Chrosziel has expanded the successful CDM Zoom Servo Drive family.
The Zoomer is a compact and universal zoom motor that can be pivoted to almost any lens by simply mounting it on a 15mm rod. The universal motor unit CDM-UNI-Z2 fits seamlessly into the operating functions of the Sony cameras of the FX9 / FX6 / FS7 / FS5 series. The servo drive is controlled via the zoom rocker on the handle. The motor control can be addressed via Sony's camera-specific protocol and also works independently of the camera signals when a digital LANC zoom rocker is plugged directly into the servo.Due to the included Chrosziel Flexi toothed ring (#206-30), the Zoomer can be used with almost any zoom lens even without standard cine gearing.
The multi-function handgrip, which in addition to the recording function and a zoom rocker also provide control over the camera menu and other freely selectable functions, are extremely popular on current video cameras with large sensors and are indispensable for effective operation.
The Chrosziel Universal Zoom Servo Drive now allows optimal use of all manual zoom lenses together with the multi-function handgrip. For this purpose, the Zoomer is slid onto a 15mm rod and swiveled onto the zoom lens. Two plug-in cables establish the connection with the camera. One cable is used for the power supply from the camera battery, the second for the connection to the control commands between the handle and the camera. When using a standard LANC zoom rocker or handle with the Sony PXW-FS5, PXW-FS7 and PXW-FS7II, the servo is connected between the handle and the camera via an input and an output jack to receive all zoom control signals. For setup with the Sony PXW-FX9 camera, a Y-cable is used that accepts the Sony multi-connector and connects to both the input jack of the Zoomer and the input jack of the camera.
For the Sony ILME-FX6 camera, a Y-cable is used and connects the 3.5mm connector of the Sony handgrip, input jack of the Universal Zoom Servo Drive, and the Sony camera.
FEATURESUniversal zoom motor
The Zoomer is a compact and universal zoom motor that can be pivoted to almost any lens by simply mounting it on a 15mm rod.
Controlled via Sony and Digtial LANC handgrip
The Sony FX6 / FX9 / FS5 / FS7 handgrip zoom rocker controls directly the servo drive unit. Other zoom rockers with digital LANC protocol are compatible too, e.g. mounted handgrip.
Camera control signals forwarded
Control commands are immediately looped through to the camera (e.g. menu / user buttons / focus magnification / camera run & stop).
Panasonic DC-BS1H & DC-BGH1 box cameras A recent firmware updated has made the CDM-UNI-Z2 compatible with the Panasonic BS1H and BGH-1 box cinema cameras when used with a Manfrotto MVR901EPLA and MVR901ECLA control handles as well as the digital LANC Libec ZFC-L and ZC-LP zoom controllers. Technical dataPower supply 10-30V (Lemo compatible 0B 5-pin)
2.5mm socket (control command In)
3.5mm socket (control command In&Out)USB Type min A-B (firmware updates)
Torque 0.5Nm
Power consumption max. approx. 350mAh @ 12VIN THE BOX
1x CDM-UNI-Z2 Digital motor unit
1x LANC cable
1x LANC extension cable
1x MN-AB-A90 (power supply cable 12 Volt A/B D-Tap – angled 90° rotated 0B 5pin) 1x 206-30 Flexi Gear Ring (Ø 60-120mm)
1x Gear Drive, mod. 0.8 (Ø 40mm)
1x CAB-FX9 for Sony PXW-FX9 compatibility
1x CAB-FX6 for Sony PXW-FX6 compatibility
USB Mini AdapterSign up for ZOOMER email updatesDon't miss future news about the ZOOMER and subscribe to the Zoomer Email list. Yes, keep me updated about the ZOOMER and send me future news about it.NOTE: we will not use your email for any other emails not related to the Zoomer.
hbspt.forms.create({
region: "na1",
portalId: "2769585",
formId: "aae38178-6132-4e21-b6b4-bd9ac7e2828f"
});
Adjustable Cable Ties With Multiple Mounts.One of the little things that makes life easier on setSet with 12 pcs "Chaos Cable Ties"4x 1/4" thread4x 3/8" thread 4x stickytapeOrganize your cables on your camera set with our Chaos Cable Ties. These adjustable, reusable ties are great for managing cable on set. they also reduce cable strain as they keep the cable from sliding through unlike other ties. The set comes with 4 ties that have a 3/8th thread and 4 that have 1/4-20 thread to attached to cages and organize cables around the camera they way you want. Because of the thread, you can use them again and again. No threaded mount points available? Chrosziel has you covered with 4 adhesive Chaos Cable Ties in the set.
Light weight support for Sony ILME-FX6, with integrated shoulder pad, 2 rosettes, VLock-Plate, Tripod Adapter Plate, 2 rods Ø 15mm, l. 205mm.Lightweight support (LWS) for Sony FX6 cameras Four positions are provided on the light support for the 3-point camera attachment, which allows the camera to be attached to the light support without distortion. This guarantees parallel alignment of the optical axis to the light support and the attached compendium.
A specially hardened V-lock plate allows the light support to be used on the tripod with the standard Sony VCT-14/VCT-U14 adapter plate, the Chrosziel V-Mount Quicklock plate (401-150) or compatible adapter plates from other manufacturers in a stable two-point lock. The V-Lock plate under the light support can be easily exchanged by the user for the tripod adapter plate (401-FS7/5-03). This allows other adapter plates, such as the Sachtler plate, to be firmly screwed to the light support. The attachment points of common adapter plates are taken into account. Both the Chrosziel V-Lock plate and the tripod adapter plate have captive screws.The shoulder pad under the light support can be moved over a wide range. A lever clamp mechanism with external lever access allows the user to slide it on the shoulder. This allows him to quickly correct the balance of the camera during operation. The pad is tapered to fit the shoulder and has an elevation toward the neck for side protection. After fully opening the lever clamp, the pad can be removed and inserted rotated 180 degrees, so that one can equally use the light support on the left or right shoulder. The pad itself is manufactured using a new process from the automotive industry in a special mold with a molded core surrounded by an elastic material with a strong durable outer shell. This multi-layer construction results in high comfort and fatigue-free work.At the front of the light support, 15mm tubes are attached with one clamping lever each. On both sides of the light support there are Hirth rosettes (Arri compatible) for attaching handles or other accessories.The optional rear tube clamp can be screwed to the rear end of the light support. With additional 15mm tubes, battery adapter plates, video transmitters, video recorders or other accessories can be attached behind the camera in a variable and movable way. Alternatively, there are four screw points (1/4 and 3/8" with Arri anti-twist protection) at the top of the rear part of the light support for accessories.The Chrosziel light support of the FX6 is the optimal result of stability and weight due to a sophisticated design. It is manufactured in Germany.INCLUDED IN BOXIntegrated shoulder pad2 rosettesVLockPlateTripod Adapter PlateOne pair of rods: Diameter: 15mm, Length: 205mm
Handgrip Extender with bayonet lock for Sony PXW-FX6, extendable from 175 to 250mm, incl. extension cable, length 300mm, Hirth-Rosette with screws. For use with Chrosziel LWS 401-FX6 or directly on the camera with included Hirth-Rosette.
The Chrosziel Meta Mount is a Sony E camera to PL lens “hot mount”
adapter with metadata communication. Each mount has the required pin contacts
necessary to transmit lens metadata through to the camera and conversely the
contacts provide lens control through a 12-pin Hirose out connection to an ENG
lens.
When the Meta Mount is used with cine lenses with LDS or Cooke/i Data
the metadata such as iris setting, focus distance and zoom focal length are
transmitted through the adapter and appear in the viewfinder, on the monitor
and are recorded in the video file for use in post processing.
When the Meta Mount is used with an ENG servo motor-controlled broadcast
lens the Focus/Iris/Zoom servo’s can be controlled through the camera and are
compatible with the Sony FX9 / FX6 / FX3 hand grips, RCP or camera’s web GUI.
This allows for easy and full control of an ENG broadcast lens through a Sony E
mount camera.
The Meta Mount is shimmable with the included shim set for the E-mount.Key Features:
·
Sony E Mount Camera to PL mount Lens
·
Electronic contacts for metadata communication and
lens control
·
Lens metadata displayed in camera and recorded to file
·
Shimmable E Mount
·
Full focus/Iris/Zoom control on servo motor ENG lenses
Technical data:
- E Mount camera to PL mount lens
- Contact and electronics for Metadata communication
- 12-pin Hirose out for ENG lens control
- 3/8th lens support socket
- USB Type min A-B (for firmware updates only)
- Power supply 10-16V (Lemo compatible 0B 5-pin)
- Power consumption max. ca. 350mAh @ 12V
- Part number MA-EPL-HR12
- EAN number: 4250618846934
In the box:
- 1x Meta Mount E-to-PL adapter (MA-EPL-HR12)
- 1x MN-AB (power supply cable 12 Volt A/B D-Tap – 0B 5-pin Lemo)
- 1x F55-A2-P-CAM
- 1x Shim Set, E-Mount side
- 1x USB Mini Adapter
Sign up for META MOUNT email updatesDon't miss future news about the META MOUNT and subscribe to the META MOUNT Email list. Yes, keep me updated about the META MOUNT and send me future news about it.NOTE: we will not use your email for any other emails not related to the Meta Mount.
Hirth-Rosette for Sony ILME-FX6, mounted inside the bayonet lock of FX6 handgrip . For use with Chrosziel 403-FX6 handgrip extension or Hirth-Rosette accessories.
KIT - Lightweight support (LWS) for Sony FX 6 cameras.Lightweight supportFour positions are provided on the light support for the 3-point camera attachment, which allows the camera to be attached to the light support without distortion. This guarantees parallel alignment of the optical axis to the light support and the attached compendium.
A specially hardened V-lock plate allows the light support to be used on the tripod with the standard Sony VCT-14/VCT-U14 adapter plate, the Chrosziel Quicklock plate or compatible adapter plates from other manufacturers in a stable two-point lock. The V-Lock plate under the light support can be easily exchanged by the user for the tripod adapter plate (401-FS7/5-03). This allows other adapter plates, such as the Sachtler plate, to be firmly screwed to the light support. The attachment points of common adapter plates are taken into account. Both the Chrosziel V-Lock plate and the tripod adapter plate have captive screws.
The shoulder pad under the light support can be moved over a wide range. A lever clamp mechanism with external lever access allows the user to slide it on the shoulder. This allows him to quickly correct the balance of the camera during operation. The pad is tapered to fit the shoulder and has an elevation toward the neck for side protection. After fully opening the lever clamp, the pad can be removed and inserted rotated 180 degrees, so that one can equally use the light support on the left or right shoulder. The pad itself is manufactured using a new process from the automotive industry in a special mold with a molded core surrounded by an elastic material with a strong durable outer shell. This multi-layer construction results in high comfort and fatigue-free work.
At the front of the light support, 15mm tubes are attached with one clamping lever each. On both sides of the light support there are Hirth rosettes (Arri compatible) for attaching handles or other accessories.
The optional rear tube clamp can be screwed to the rear end of the light support. With additional 15mm tubes, battery adapter plates, video transmitters, video recorders or other accessories can be attached behind the camera in a variable and movable way. Alternatively, there are four screw points (1/4 and 3/8" with Arri anti-twist protection) at the top of the rear part of the light support for accessories.
The Chrosziel light support of the FX6 is the optimal result of stability and weight due to a sophisticated design. It is manufactured in Germany.
Top Plate FX6
The Chrosziel Top Plate FX6 is slid over the carrying handle from behind and attached to the camera with four screws. The plate offers multiple mounting options on the sides and top with ¼" and 3/8" holes for wide accessories. Sony's tape measure pin can be screwed into the Top Plate on the left or right side. There are also six mounting points on the plate for Sony's 4 cable clamps. The FX6 carrying handle can also be removed with the Top Plate screwed on, for example for gimbal use.
Handle extension FX6
The FX6 camera's control handle connects directly to the camera body via the same Sony proprietary bayonet mount as the FS5, and can be adjusted in angle via a switch on the handle. The Chrosziel FX6 Handgrip Extension is extendable from 175 to 250mm and has the Sony bayonet mount at the lower end. The FX6 operating handle can be inserted directly into the Chrosziel handle extension. To connect the handle extension to the camera, an adapter piece with Hirth rosette is inserted into the camera-side bayonet connection. The Chrosziel handle extension also has a rosette at the upper end and can be screwed into the camera with the adapter piece. When using the FX6 light support, the handgrip extension can be attached directly to the rosette of the light support. This provides great flexibility in mounting options. The handgrip extension includes a 300mm extension cable with 3.5mm jack (4-pin) connection for signal routing between handgrip and camera.
The adapter piece with Hirth rosette is also supplied as a single part and allows other accessories to be attached to the FX6 camera.
In the BoxLightweight support (LWS) with V-Lock plate and tripod adapter plate 401-FS7/5-03
2 tubes Ø 15 mm, L. 205mm
rear tube clamping
Top Plate,
Handle extension
Hirth rosette with screws
extension cable, L. 300 mm
All parts of the LWS FX6 kit are also available separately.
Top-Plate for Sony PXW-FX6, with integrated mounting points 1/4" and 3/8".TOP PLATE FX6
The Chrosziel Top Plate FX6 is slid over the carrying handle from behind and attached to the camera with four screws. The plate offers multiple mounting options on the sides and top with ¼" and 3/8" holes for wide accessories. Sony's tape measure pin can be screwed into the Top Plate on the left or right side. There are also six mounting points on the plate for Sony's 4 cable clamps. The FX6 carrying handle can also be removed with the Top Plate screwed on, for example for gimbal use.
Universal Lensport Iris Motor for cine lenses in Broadcast / ENG Run& Gun setups
The universal Iris Motor is a compact and universal Iris motor that can be pivoted to almost any lens by simply mounting it on a 15mm rod. The universal motor unit CDM-LP-I fits seamlessly into the operating functions of any camera with Hirose 12pin lensport communcation. The servo drive is controlled via the 12pin Hirose output of the camera. The motor control can be addressed via the camera-specific Broadcast protocol and also works in conjunction with e.g. the MetaMount E-to-PL adapter.The Chrosziel Lensport Iris Motor now allows optimal use of all manual zoom and prime lenses together with any camera with Hirose 12pin output. For this purpose, the Iris motor is slid onto a 15mm rod and swiveled onto the zoom or prime lens. The curled Hirose 12pin cable establish the connection with the camera.
Compatibility: The Universal Iris Motor has been successfully tested with the following cameras (manual and automatic iris control):
ARRI Amira
Blackmagic URSA Broadcast G2 & URSA Mini Pro 12K
Canon C300/500 with EU-V2 expansion unit
Panasonic AK-PLV100
Sony F5/F55 with LA-FZB1 adapter
Sony Venice
Sony E-Mount cameras with Chrosziel MetaMount MA-EPL-HR12
Manual Passive Mode: For temporary manual control, the motor can be set to passive mode. Simply press the motor button once briefly and the motor can be rotated freely. Once the button is pressed again, the motor is back in Active mode and controlled by the camera. Metadata:For setup, the cable is connected to the Hirose 12pin socket of the camera. The motor automatically calibrates itself and finds the endstops of the lens. For metadata calibration, the motor needs to learn T-Stop 4 and 16. With the press of the only button, the motor goes into passive mode and the user can turn the motor without resistance. The motor is turned to T-Stop 4 and the the press of the button confirms the position. Afterwards the motor is turned to T-Stop 16 and the position is confirmed with another press of the button. Ready!
FEATURESUniversal Iris motor
The Iris Motor is a compact and universal Iris motor that can be pivoted to almost any lens by simply mounting it on a 15mm rod.
Controlled via any Hirose 12pin camera outputThe camera's Hirose 12pin Lensport output controls directly the Iris motor unit. Remote Iris and AutoIris controlUse the Iris motor in a remote setup and control it via the RCP or WebGUI of any camera with Hirose 12pin connector. Or switch on the AutoIris functionality of your camera and the camera uses the Chrosziel Univeral Iris Motor for AutoIris control.
