Choose your camera brand and we will show you the matching Chrosziel Accesssories.
Chrosziel Camera Accessories for:
ARRI ALEXA, ARRI ALEXA Mini, ARRI AMIRA
Chrosziel Camera Accessories for:
Blackmagic Cinema, Blackmagic Pocket, Blackmagic Production, Blackmagic Studio
Chrosziel Camera Accessories for:
Canon EOS 1D MARK IV, Canon EOS 5D, Canon EOS 7D, Canon EOS C100, Canon EOS C300, Canon EOS C300 MARK II, Canon EOS C300 MARK III, Canon EOS C500, Canon EOS C500 MARK II, Canon EOS C700, Canon EOS C70, Canon XF 305
RED Epic Dragon, RED Raven, RED Scarlet, RED Weapon
Chrosziel Camera Accessories for:
Sony ALPHA A7, Sony ENG V-Mont Shoulder Cameras, Sony NEX-FS100, Sony NEX-FS700, Sony PMW-F3, Sony PMW-F5, Sony PMW-F55, Sony PMW-F365, Sony PXW-FX5, Sony PXW-FX6, Sony PXW-FX9, Sony PXW-FX7
Articulating arm ROCKY with 2-step central clamp, with 1/4" thread and cold shoe adapter L. 150 mm, weight 158 gr., payload 3 kg. The central clamp first fixes the articulation and second the ball pivot. The 90° slot is rotating and can be fixed.
Bridge Plate with Ø19mm rods, L= 720mm, for Sony F23, F35, F65 and with LWS as adaptor for Red Epic / Scarlet, Canon C300, C100, C500 and with LWS 401-444HD
Bridge Plate with Ø19mm rods, L= 440mm, for Sony F23, F35, F55, F65, Phantom Flex and with LWS as adaptor for Red Epic / Scarlet, Canon EOS C Series and other
Bridge Plate with Ø19mm carbon rods, L= 500mm, for Sony F23, F35, F65 and with LWS as adaptor for Red Epic / Scarlet, Canon C300, C100, C500 and wth LWS 401-450HD for all cameras wth an optical axis height between 45 and 66 mm.
Cage for Dream Chip ATOM one SSM500, compatible with both B4- and C-Mount Version, with 3/8" and 1/4" anti-twist threads, top handle 401-HANDLE, sensor
plane marker and tripod plate.
CDM-MK-Z2 - compact control-unit for Fujinon Zoom MK 18-55, 50-135mm for controlling zoom. For usage with orig. Sony handgrip (PXW-FS5, PXW-FS7) or LANC zoom devices. Incl. 1x digital servo-motor-unit, 1x LANC cable, 1x LANC extension cable, 1 x MN-AB (powercable 12 Volt A/B D-Tap 0B 5pin), 1x Allen Key, 1x Mini-USB-adapter.DESIGNED FOR FUJINON MK 18-55MM T2.9 & FUJINON MK 50-135MM T2.9
CONTROLLED VIA SONY FS & LANC HANDGRIP
Control directly the zoom servo drive via optically de-coupled LANC sockets and Sony FS5 / FS7 handgrip zoom rocker. Other zoom rockers with LANC protocol are compatible too, e.g. mounted to handgrip.
CAMERA CONTROL SIGNALS FORWARDED
Control signals (e.g. menu / user buttons / focus magnification / camera run & stop) are immediately looped through to the camera.
SINGLE UNIT MOUNTED ONTO LENS
Two captive screws keeping the single servo drive unit permanently fixed onto lens.
4 ZOOM MODES
1st EB / Documentary, 2nd Live / Hardcut, 3rd Silent, 4th Direct Mode
Chrosziel further expands its successful CDM Zoom Servo Drive family
The FR7 zoom motor unit CDM-SFR fits seamlessly into the operating
functions of the Sony PTZ ILME-FR7 camera.
The FR7 Zoom Servo Drive is a compact and universal zoom motor that can be pivoted to almost any lens by simply mounting it on the 15mm rods of the Sony PTZ head. The servo drive is controlled via the Option port of the Sony ILME-FR7. The motor control can be addressed via Sony's camera-specific protocol and therefore can be used seamlessly with the whole ecosystem of the Sony FR7.Due to the included Chrosziel Flexi toothed ring (#206-30), the CDM-SFR can be used with almost any zoom lens even without standard cine gearing.
This opens up a complete new range of lenses to cover the creatives needs from wide angle lenses to long-zoom operation.The FR7 Zoom servo drive unit is slid onto the 15mm rod and swiveled onto the zoom lens. The curly cables ensure safe operation within the full tilt and pan range of the Sony ILME-FR7. The tiny distribution box is mounted to the side of the FR7 base and has a built-in power input. Simply unplug the power supply of the FR7 and plug it into the distribution box. Then plug the power plug of the distribution box into the power input of the Sony FR7. Connect the RJ45 connector of the distribution box into the OPTION port of the cameras base unit (do not connect to the Ethernet port since you need this for the ILME-FR7 communication). Done.FEATURESUniversal zoom motor
The CDM-SFR is a compact and universal zoom motor that can be pivoted to almost any lens by simply mounting it on the 15mm rod.
Controlled via Sony ILME-FR7
The Sony ILME-FR7 base unit controls directly the servo drive unit. What ever remote panel or web access you use to control the Sony ILME-FR7, the zoom motor will receive its signal directly from the base unit of the FR7.No extra cables or power supply neededThe CDM-SFR inherits all cables, clamps, distribution box and plugs to use it right out of the box with the Sony ILME-FR7. No extra power supply needed.
Technical dataPower IN 19.5V (Sony ILME-FR7 power supply used)
Power OUT (Sony ILME-FR7 power plug, same voltage as power in passed through)RJ45 plug (control command In (OPTION port))
Torque 0.5Nm
Power consumption max. approx. 10Wproduct code CDM-SFR EAN/GTIN number: 4250618848648
IN THE BOX
1x CDM-SFR Digital motor unit
1x 206-30 Flexi Gear Ring (Ø 60-120mm)
1x Gear Drive, mod. 0.8 (Ø 30mm)
CDM-MK-Z2 - servo drive unit for Fujinon Zoom XK 20-120mm for controlling zoom. For usage with orig. Sony handgrip (PXW-FS5, PXW-FS7) or LANC zoom devices. ZOOM SERVO DRIVE FOR FUJINON XK ZOOM LENS: CDM-XK-Z
MOTORIZE YOUR FUJINON XK6X20 20-120MM T3.5 WITH CHROSZIEL
SINGLE UNIT MOUNTED ONTO LENSTwo captive screws keeping the single servo drive unit permanently fixed onto lens.CONTROLLED VIA SONY FS & LANC HANDGRIPThe Sony FS5 / FS7 handgrip zoom rocker controls directly the servo drive unit. Other zoom rockers with LANC protocol are compatible too, e.g. mounted to handgrip.CAMERA CONTROL SIGNALS FORWARDEDControl signals (e.g. menu / user buttons / focus magnification / camera run & stop) are immediately looped through to the camera.4 ZOOM MODESEB / Documentary, Live / Hardcut, Silent, Direct Mode_________________________________________________________________All in one single housing
Developed for the Fujinon XK6x20 20-120 mm zoom lens the CDM-XK-Z enables ways of creativity that may be impossible just by zooming manually. To simplify the operator’s workflow the zoom servo drive is directly mounted onto the lens by two captive screws.
The weight of the CDM-XK-Z including digital motor, gear, PCB with CPU, screws and cabling is 0.44 lbs. (197 gram). With the zoom servo drive Chrosziel addresses camera operators who are working in the broadcast and documentary sector looking for a reasonably priced zoom servo drive.
_____________________________________________________All camera control signals forwarded
Control commands (e.g. menu / user buttons / focus magnification / camera run & stop) are immediately looped through to the camera via the LANC protocol.
By using a Sony PXW-FS5 or a Sony PXW-FS7 camera with a SWIT battery a D-Tap to a (straight or angled) Lemo compatible 5-Pin power cable is used (Chrosziel order numbers: MN-AB-A with angled Lemo compatible socket / MN-AB with straight Lemo compatible socket). The two Jack-Jack cables are forwarding the control commands from the hand grip.
If e.g. a Panasonic Varicam, Sony PMW-F5 or Sony PMW-F55 are used a combined cable with power and start / stop is required, like a Hirose 4-Pin to a (straight or angled) Lemo compatible 5-Pin cable (Chrosziel order numbers: F55-A2-PCAM-A with angled Lemo socket / F55-A2-PCAM with straight Lemo compatible socket). Also, the two Jack-Jack cables are forwarding the control commands from the hand grip.
Also, Chrosziel offers a variety of power cables with straight and angled plugs for all types of camera power out sockets and batteries including camera run / stop functionality.
_____________________________________________________Chrosziel CDM-XK-Z Zoom Servo Motor: zoom modes
For freedom of creativity the operator may choose from four different zoom modes: EB / Documentary Mode, Live / Hardcut Mode, Silent, and Direct Mode.
EB / Documentary ModeDesigned for long and smooth zoom drives with the CDM-LWZ3-Z it offers slow creeping zoom transitions while keeping the motive perfectly framed.Silent ModeTo reduce the sound of the zoom servo drive the maximum speed of its motor is limited to 40 percent making the setup almost inaudible.Live / Hardcut ModeTo catch the best moments, the Live / Hardcut Mode is useful. It uses 80 percent of the maximum speed capacity of the motor offering fast zoom drives but with Soft Ramping.Direct ModeThe Direct Mode finally uses the full speed capacity of the Zoom Servo Drive. The LANC commands are implemented instantaneously without ramping and smooth transitions. Useful for B camera operators catching snaps shots from the concert.______________________________________________________________How to change zoom modes
You can choose the different modes by pressing the zoom rocker for round about 25 seconds, then the green LED flashes very fast while changing the zoom mode and after that it blinks 1, 2, 3 or 4 times* – depends on the zoom mode you chose (* 1 = EB / Documentary / 2 = Silent / 3 = Live / Hard Cut / 4 = Direct). To cycle through these all you need to do is hold the zoom rocker down one way for a couple of seconds to switch to the next mode, and the other way, hold to reverse.
CF carbon rods (set of 2) for lightweight support, Ø15mm, length 500mm De Luxe version: Ground to 2/100 mm precision, with thread for extensions, weight 105 g (pair).
Adjustable Cable Ties With Multiple Mounts.One of the little things that makes life easier on setSet with 12 pcs "Chaos Cable Ties"4x 1/4" thread4x 3/8" thread 4x stickytapeOrganize your cables on your camera set with our Chaos Cable Ties. These adjustable, reusable ties are great for managing cable on set. they also reduce cable strain as they keep the cable from sliding through unlike other ties. The set comes with 4 ties that have a 3/8th thread and 4 that have 1/4-20 thread to attached to cages and organize cables around the camera they way you want. Because of the thread, you can use them again and again. No threaded mount points available? Chrosziel has you covered with 4 adhesive Chaos Cable Ties in the set.
401-BUR-ADV-KIT: THE COMPLETE LWS CAGE FOR THE SONY BURANOThe Chrosziel Advance Cage Kit fitted for the Sony Burano is a slim, lightweight yet sturdy cage that allows access to all camera controls and ports while adding dozens of mounting points for essential gear and accessories the camera needs for filming. The Advanced cage kit is perfect for run-n-gun shooting, live event broadcasting or tripod mounted studio work.
Fitted LWS Baseplate with VCT mount, shoulder pad and 15mm rod mounts, a pair of 20 cm rods in is included Top-Plate for Sony Burano, built-in Ø15mm rod attachment, with integrated mounting points and a pair of 9cm rods included. Top plate has removeable center so FX9 handle with built in electronics can be used Right and Left front side brackets with more mounting points Rear right side bracket that secures to the top plate and the camera with 2 extra screws to support heavier accessories
The 401-BUR-ADV-KIT Chorsziel Cage Consists of: 1x 401-VEN LWS base plate with integrated shoulder pad 1x 401-BUR-TOP Top plate with 15mm rods 1x 401-BUR-SBF Front side bracket right 1x 401-BUR-SBL Front side bracket Left 1x 401-BUR-SBR Rear side bracket
Chrosziel Cine Bridge Plate Kit for Sony Venice 2 consists of: Top Bridge 401-VEN-BRI, Bridge plate 401-121-02, cage brackets left and right, and top plate.
Chrosziel Front-Side-Bracket for Sony Burano, with integrated mounting points 1/4" and 3/8". The front-side-plate is attached to the Chrosziel top plate (401-BUR-TOP) and to the light weight support (401-VEN) or bridge plate (401-VEN-BRI).401-BUR-SBF: THE SONY Burano Front Side BracketThe Front Side Bracket comes with numerous 3/8″ & 1/4″ fastening points with ARRI anti-twist safeguard. It is mounted with two screws into the Chrosziel 401-BUR-TOP top plate and additionally into the two threading of the Chrosziel Light Weight Support 401-VEN or Chrosziel Bridge Plate 401-VEN-BRI.
Front Side Bracket for Sony Burano, with integrated mounting points
1/4" and 3/8" threads
mounted on the Chrosziel 401-BUR-TOP top plate and the two threading of the Chrosziel 401-VEN or 401-VEN-BRI
€196.00*
